• 4711377286572

model

• PRO B860-P WIFI

Processor support

• Intel® Core™ Ultrav
• chassisLGA1850

Chipset

• ChipsetB860

Memory

• Memory support4x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support 9200
• Maximum memory256GB DDR5
• Free slots4

Connections

• HDMI0
• HDMI 2.11x HDMI™ Support HDMI™ 2.1
• DISPLAY PORT1
• Type-C DisplayPort1
• PCI-E X164
• PCI-E X10
• Thunderbolt 4 ports1
• Front and rear4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 4x USB 5Gbps Type A (Front) 2x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Front) 1x USB 40Gbps Type C (Rear)

Expansion slots

• PCIe 5.0 x161
• PCIe 4.0 x161
• PCIe 3.0 x10

• m.23
• sata III4

Disk Management

• RAID supportv

communication

• LANIntel® Killer™ E5000 5Gbps LAN
• wifi + BTIntel® Killer™ BE1750x Wi-Fi 7

Audio

• HD 7.1v

video

• AMD® CrossFire supportv

Special

• CoolingExtended Heatsink Design

Internal IO

• Connections1x Thunderbolt5 card connector(JTBT5, support RTD3) 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 4x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Aud
