Description
Chipset
AMD WRX80 Chipset
Socket
sWRX8 4094 socket
MB Form Factor
E-ATX
Memory Type
ECC REG
\Â DDR4
\Â ECC RDIMM
\Â LRDIMM
\Â 3DS R-DIMM
DDR4 Slots
8
Storage Interface
SATA3
\Â M.2 PCIe
\Â U.2 connector
SATA3 Ports
4
M.2 PCIe Connectors
4
RAID
0,1
\Â 0,1,5,10
MB Expansion Slots
Trusted Platform Module (TPM)
PCI-E x16
6
USB2.0 Ports
2
USB3.2 Ports
10
USB Type-C
1
Front USB Connector
USB 2.0
\Â USB 3.0
\Â USB-C
Graphics O.B
ASPEED AST2600 BMC chip
Graphics Interface
VGA
O.B Audio
5 port S/PDIF
LAN
GIGABIT LAN
\Â 10 GIGABIT LAN
Network Connections
GIGABIT LAN
\Â 10 GIGABIT LAN
COM Port
Yes
Package
Bulk
Information
| CPU Supported: 1x AMD Threadripper PRO 3000WX Series, up to 64-Core Memory: Support both of ECC/Non-ECC UDIMM and ECC RDIMM, max capacity is up to 256GB(UDIMM) or 2TB(RDIMM), DDR4-3200MHz (1DPC) in 8 DIMM slots |
 |
 |
Support 6 GPU cards (PCI-E 4.0, run in 16/16/16/16/16/16) for Professional Workstation for intensive AEC, DCC, AI, VR and graphics workloads Support 4 M.2 Socket, PCI-E 4.0 x4 via CPU, RAID 0, 1, 5, and 10 |
| Support 2 U.2 Sockets, PCI-E 4.0 x4, support Software RAID 0, 1 PLUS 4 SATA 3.0 connectors (RAID 0, 1, 5, and 10) 1 USB 3.2 Gen 2×2(Type-C, 20Gb); 5 USB 3.2 Gen 2 (4 Type A, 1 front Intel Type-C header, 10 Gb); 5 USB 3.2 Gen 1 (3 Type A, 1 front Type A header=2 ports, 5Gb); 2 USB 2.0 (1 type A Header=2 port support) |
|
|
1 AQC113C 10Gb RJ45 LAN port+ 1 Gbit LAN Ports (Intel i210AT, shared with IPMI) Form Factor: EATX 12″x13″. Heatsink/Fan Sold Separately |
