Description
Interface :3 10/100Mbps LAN Ports, 1 10/100Mbps LAN/WAN Port, / Archer MR400 APAC.
1 Micro SIM Card Slot
Button :WPS/Reset Button, WiFi On/Off Button, Power On/Off Button
External Power Supply :12V/1A
Dimensions ( W x D x H ) :7.95 × 5.55 × 1.32 in. (202 × 141 × 33.6 mm)
Antenna :V2: 2 Internal 4G LTE Antennas
V3/V1: 2 Detachable 4G LTE Antennas
WIRELESS FEATURES
Wireless Standards :IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
Frequency :2.4GHz and 5GHz
Signal Rate :300Mbps at 2.4GHz, 867Mbps at 5GHz
Reception Sensitivity :5GHz: 11a 54M: -74dBm
11ac HT20: -67dBm
11ac HT40: -64dBm
11ac HT80 : -60dBm
11n HT20: -71dBm
11n HT40: -70dBm
2.4G: 11g 54M: -76dBm
11n HT20: -73dBm
11n HT40: -67dBm
Transmit Power :CE: <20dBm(2.4GHz), <23dBm(5GHz)
Wireless Functions :Enable/Disable Wireless Radio, WMM,
Wireless Statistics
WAN Failover :Yes
Wireless Security :64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
Network Type :4G: FDD-LTE B1/B3/B7/B8/B20 (2100/1800/2600/900/800MHz)
TDD-LTE B38/B39/B40/B41 (2600/1900/2300/2500MHz)
3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900MHz)
SOFTWARE FEATURES
Quality of Service :Bandwidth Control
Operating Modes :3G/4G Router, Wireless Router
WAN Type :Dynamic IP/Static IP/PPPoE/PPTP/L2TP
Management :Access Control, Local Management, Remote Management
reboot schedule
DHCP :Server, Client, DHCP Client List, Address Reservation
Port Forwarding :Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS :DynDns, NO-IP
VPN :PPTP VPN, IPSec VPN , OpenVPN
Access Control :Parental Control, Local Management Control
Firewall Security :DoS, SPI Firewall, IP Address Filter/Domain Filter,
IP and MAC Address Binding
Protocols :Supports IPv4 and IPv6
Guest Network :2.4GHz guest network x 1, 5GHz guest network x 1
IPSec VPN :Supports up to 10 IPSec VPN tunnels
