Description
Factory data
Country of origin
China
Common parameters
Type
Video card
Model
MSI GeForce RTX 3060 VENTUS 2X OC (LHR)
Manufacturers code
[RTX 3060 VENTUS 2X 12G OC]
LHR
Yes
Main parameters
Graphics processor
GeForce RTX 3060
Microarchitecture
NVIDIA Ampere
Technical process
8 NM
Video memory specifications
Video memory capacity
12GB
Memory type
GDDR6
Memory bus bit depth
192 bit
Maximum memory bandwidth
360 GB/sec
Effective memory frequency
15000MHz
Video Processor Specifications
The regular frequency of the video chip
1320MHz
Turbo frequency
1807MHz
Number of universal processors (ALU)
3584
Number of texture units
112
Number of rasterization blocks
64
Ray tracing support
Yes
Hardware acceleration of ray tracing (RT cores)
28
Tensor kernels
112
Shader version
6.4
Image Output
Video connectors
DisplayPort x3, HDMI
HDMI version
2.1
DisplayPort version
1.4
Number of monitors connected at the same time
4
Maximum resolution
Ultra HD 8K (7680×4320)
Connection
Connection interface
PCI-E 4.0
Connection connector form factor
PCI-E x16
Additional power connectors
8-pin
Recommended power supply
550W
Cooling system
Type of cooling
active air
Type and number of installed fans
2 axial
Dimensions and weight
Low profile card (Low Profile)
No
Number of expansion slots occupied
2
Video card length
235mm
Video card width
124mm
Video card thickness
42mm
Weight
682g
Additionally
Highlighting of video card elements
